Weatherproof Light Switch

Large Image : Weatherproof Light Switch

Product Details:

Place of Origin:	China
Brand Name:	KRIPAL
Certification:	CE,
Model Number:	UKW-1GSS

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	negotiable
Packaging Details:	Each unit packed in a individual box
Delivery Time:	20 days and depends on ordering quantity
Payment Terms:	T/T, L/C
Supply Ability:	50000 pcs per month

Contact Now

Detailed Product Description

Switch:	1 Gang 1 Way	Socket:	13A BS Standard
Enclosure:	PC	Button:	ABS
Protection Grade:	IP55	Color:	RAL Grey
Highlight:	Outdoor Plug Socket

IP55 Waterproof switch Socket

UKW series waterproof switch socket is used in-house & Outdoor for power supply and IP55 protection of water & dust.

Description:

Accepts module series accessories (and basic series accessories with specific bearing adaptors)

Protection degree: IP55 with the cover closed

Cable accessories: Three 23mm knock out openings and one with PG16 cable sleeve

Resistance to fire: Glow-wire test 650 degree

The frame can be attached to the base before securing the fixing screws, easy installation

The diameter of mounting holes on wall is 4.4mm

The switching operation can be undertaken through the transparent membrane

Installation: surface or flush mounting

It is possible to install more than one box closed together

Raw materials:

Enclosure: brand-new PC;

switching button: ABS,

other plastic parts: nylon

Metal parts: stainless steel, copper & silver

Specifications:

Product	Waterproof switch socket
Color	Grey RAL7035
Protection	IP20/IP55
Rated current	13A
Operation voltage	250V
Socket	British(BS) standard
Switch	Single pole single throw (SPST)

Dimensions:

Weatherproof Light Switch 0

Declaration:

KRIPAL is a factory with more than 25 years manufacturing experience and the mold tooling are built in our own mold tooling center. Furthermore our items are different from others to a certain degree. Hereby, we claim that KRIPAL is the only one who makes this item and the same products you got from other companies are also supplied by KRIPAL.

Why not get goods from us directly?
